Rack and Pinion mechanism with matching flat form armset
Adjustable closing speed and latch action
Backcheck
Optional Delayed action model available S510*(the product falls outside of its CE & Certifire approval with this feature in use)
Universal Application (Fig 1, Fig 6 & Fig 61)
Semi Radius cover option only
Genuine Stainless Steel material is used for all stainless steel cover variants
CE & Certifire approved product
Capable of meeting the opening force requirements of ADM and BS8300 – 830mm minimum door width at EN3 Fig 1 door mount pull side application, 807mm minimum door width at EN3 Fig 6 door mount push side application and 830mm minimum door width at EN3 Fig 61 transom mount push side application (S524)
